Spare part for led lights
Part Number: 114601
OFP-FH-RW-120-6P
High intensity flash-head including:
- 6 led projectors with molded cable
- Each projector is made in aluminium painted and do have a hard glass enveloppe
- Each projector contains 2 white independent led circuits and a red/infrared led circuit (total 12 white led circuits and 2 red/infrared led circuits)
- Stainless support for the 6 projectors and optional junction box
- No losing parts and no special tools required to remove projectors
- Junction box and/or power unit to be ordered separately
Datasheet|
Wiring
|
On stripped wires |
|
|
Operating temperature
|
Tu | -40/+55°C |
|
Weight
|
14kg for flashhead |
|
Effective light output day time at 0° on site
|
200 000cd (white) |
|
|
Effective light output twilight mode at 0° on site
|
20 000cd (white) |
|
|
Effective light output night mode at 0° on site
|
2000cd (white) |
|
|
Color day/twilight time
|
white |
|
|
Color night time
|
White |
|
|
Vertical beam spread
|
|
|
|
Horizontal beam spread
|
360° with minimum 3 flashheads fixed at 120° around the obstacle |
