Calibrated ambient sensor (photocell) for twilight-night intensity change in accordance with ICAO and FAA for all OBSTA lights or for the change of color and light-intensity

PHOTOCELL DC
Part Number: 100757
PHOTOCELL DC

  • plug-in modular construction with plated contact surfaces

  • possibility to rotate the censor on its base

  • automatic control of the red or dual obstruction lighting according to ambient light in compliance with FAA and ICAO twilight/night triggering level (2 output signals available for night and twilight)

  • timer to prevent the functioning of the cell at inopportune times (lightning)

  • this photocell is provided with a bracket to fix it on a wall and 40cm of molded cable

  • This photocell has been ETL certified to control with our dual color medium intensity L-865/L-864 for day/night change and our high intensity L-856 for day/twilight/night change

Contact Us
The ambient light sensor should be mounted upright, away from artificial light (eg., floodlights), and in a location that will enable its sensor window to have an unobstructed view of the polar sky (eg., pointed north in the northern hemisphere).
Select another reference:
PHOTOCELL AC
PHOTOCELL AC KIT
PHOTOCELL DC
PHOTOCELL-DC-KIT
Main voltage

12VDC to 48VDC -10%/+15%
Average wattage

1.5VA
Max. admissible current

2A contact closed for the night mode and 0,3A for the twilight mode
Cable diameter

Ø11mm
IP degree

IP65 in vertical position
Wiring

On 4 stripped wires 4x1,5mm² (lenght of cable 50cm) (2 power wires, 2 signal wires twilight & night)
Operating temperature
 Tu

-35°C/+60°C
Weight

0.42 kg
Weight

300g
Attachment

vertical bracket
Standards compliance

ICAO annex 14 chapter 6, FAA (AC 150/5345-43J), UK MOD, Transport Canada
Certification

FAA (AC 150/5345-43J), ETL certified, DGAC(Fr)
