Dual color medium intensity system FAA L-865/L-864 ETL certified
Part Number: 113758UA
OFI120-RW-48/240-U
- At the top: 3 flash-heads OFP-120-RW-10-U with a DC power unit, all including : Each flash-heads OFP-120-RW-10-U includes
- 2 led projectors made in aluminium and glass with 10 meters cable
- Inside each projector : 2 white led circuits and a red+infrared circuit
- Simple installation with no losing parts A DC power unit
- Normally open or normally close relay in case of lamp default or power supply
- Communication capabilities (controller, Modbus TCP)
- Test button for day and night
- Luminous indicators for quick diagnostic
- dc surge protection with indicator showing when it has failed included
- GPS controlled or in back-up activated in case of failure or absence external signals
- At the bottom: 110 to 230Vac power supply at the bottom of the obstacle
- 'Weather tight' stainless steel 316L power cabinet enclosure
- Test button with 3 positions: remote (photocell), day and night mode
- Alarm in compliance with FAA Engineering Brief 98
- Multi-layer of surge protections
- External photocell
- Master/slave configuration in case of multiple lights synchronisation
- Optional connection to side lights L-810(F) NAVILITE-IR-FAA-120-240V P/N 113969IR-F for mid level operating at night only and synchronized with red mode at the top
Photocell P/N100757, optional L-810 (F) at mid level and cable between the 2 power cabinets to be ordered separately
Dual color medium intensity FAA L-865/L-864 including 3 OBSTAFLASH120 flashheads dedicated to stack, chimney and all obstacle with a cylinder base.
Comply with ICAO medium intensity dual color type A and B. As per FAA white flashing lights L-865 used for daytime and twilight marking are recommended for obstacle exceeding 61 meters high
Certificates
Datasheet|
Main voltage
|
110VAC to 240VAC +/-10% 50/60Hz |
|
|
Average wattage
|
55W (day time), 8W (night mode) |
|
Wiring
|
For each projector, 10 meters of molded cable For power supply, 1 plug per projector + entry of power & signal cable by glands nickel plated brass and connection by terminals |
|
|
Operating temperature
|
Tu | -40/+55°C |
|
Weight
|
3,5kg |
|
|
Size of the light
|
120mm (height) x 480mm (width) |
|
|
Size of the power supply
|
590mm (height) x 350mm (width) x 250mm (dept) |
|
Standards compliance
|
ICAO annex 14 chapter 6, FAA (AC 150/5345-43J), UK MOD, Transport Canada |
|
|
Certification
|
FAA (AC 150/5345-43J), ETL certified, DGAC(Fr) |
|
IR intensity and wavelength
|
|
|
|
Effective light output day time at 0° on site
|
20 000cd (white) |
|
|
Effective light output twilight mode at 0° on site
|
20 000cd (white) |
|
|
Effective light output night mode at 0° on site
|
2000cd (red) with IR |
|
|
Color day/twilight time
|
white |
|
|
Color night time
|
Red |
|
|
Vertical beam spread
|
|
|
|
Horizontal beam spread
|
360° with minimum 3 flashheads fixed at 120° around the obstacle |
|
|
Intensity @ -10% to the ground
|
3% of max |
|
|
Flash per minute
|
40/30 as per FAA |
